Use and Care Manual Multi-temperature wine cabinet with freezer compartment, built-in WF1061/ WFI1061 050614 7084306 - 01
The appliance at a glance Contents 1 1.1 1.2 1.3 1.4 1.5 The appliance at a glance............................. Additional benefits............................................ Overview of the appliance and its equipment... Range of appliance use.................................... Conformity........................................................ Energy saving.................................................. 2 2 3 3 3 4 2 General safety information........................... 4 3 3.1 3.
The appliance at a glance 1.2 Overview of the appliance and its equipment The appliance is only suitable for refrigerating wine or food in a domestic environment or an environment that is similar to a domestic one. This includes, for example, use - in staff kitchens, bed and breakfast establishments, - by guests in country homes, hotels, motels and other types of accommodations, - for catering and similar wholesale services. Use the appliance only for normal household purposes.
General safety information 1.5 Energy saving - Always ensure good ventilation. Do not obstruct ventilation openings or grilles. - Do not install the appliance in direct sunlight or next to an oven, heater, or similar heat source. - Energy consumption depends on installation conditions such as the ambient temperature (see 1.3) . - Avoid opening the appliance door for any longer then neccesary. - The lower the temperature is set the higher the energy consumption.
Controls and displays DANGER WARNING indicates a hazardous situation, which if not avoided, will result in death or serious injury. indicates a hazardous situation, which if not avoided, could result in death or serious injury. CAUTION indicates a hazardous situation, which if not avoided, will result in minor or moderate injury. NOTICE indicates a hazardous situation, which if not avoided, could result in damage to property. Note indicates useful advice and tips. 3 Controls and displays 3.
Start-up WARNING Risk of fire due to short circuit. If the power cable or plug of the appliance or another appliance and the back of the appliance touch each other the power cable or plug will be damaged by the vibrations of the appliance which could lead to a short circuit. u Install the appliance so that it does not touch any plugs or power cables. u Do not connect the appliance or other appliances to the sockets on the back of the appliance.
Operation WARNING Electrical shock hazard! This appliance is equipped with a three-prong (grounding) polarized plug for your protection against possible shock hazards. Electrical Grounding Required. u Do not remove the round grounding prong from the plug. u Use only an grounded adapter. - Wait 1 hour after installation before you plug in the appliance. This allows the refrigerant and system lubrication to reach equilibrium. - Make sure incoming voltage is the same as the appliance rating.
Operation pressed on the control panel, the temperature display goes back to the set brightness. w The temperature is again displayed on the temperature display. 5.2.1 Setting the brightness 5.4 Door alarm The brightness can be set between h0 (minimum luminosity) and h5 (maximum luminosity). u To activate setting mode: Press SuperFrost button Fig. 2 (2) for about 5 seconds. w S is shown on the display. w The Menu symbol Fig. 2 (22) lights up. u Press Freezer compartment Up button Fig.
Operation WARNING Danger of food poisoning! No record will be kept of a power failure during Sabbath Mode. Thus, during Sabbath mode, if a power failure occurs that you are not aware of, when the power comes back on, the unit will continue to be in Sabbath Mode but when Sabbath Mode is ended there will be no indication that a power failure occurred. If a power failure occurs during Sabbath mode: u Check the quality of the food.
Operation You do not need to switch SuperFrost on in the following cases: - when placing frozen food in the freezer - when freezing up to about 2 kg of fresh food a day Freezing with SuperFrost u Briefly press the SuperFrost button Fig. 2 (2) once. w The SuperFrost symbol Fig. 2 (25) LED lights up. w The freezing temperature drops and the appliance operates at its maximum refrigeration power rating. When a small amount of food is to be frozen. u Wait approx. 6 hrs.
Operation Note u The IceMaker only produces ice cubes when the drawer is completely closed. u Wait 5 mins. Producing ice cubes The production capacity depends on the freezer temperature. The lower the temperature, the more ice cubes can be produced in a certain period. The production capacity is 90- 100 ice cubes in 24 hours at a freezing temperature of 0 °F (-18 °C). To have the maximum capacity of approx. 130 ice cubes in 24 hours, activate the SuperFrost Function.
Maintenance w When the button is pressed for the first time the previous value is displayed on the top wine cooling zone temperature display Fig. 2 (8) or on the bottom wine cooling zone temperature display Fig. 2 (7). u To change the temperature in 1 °F (1 °C) steps: Press the button briefly. -oru To change the temperature continuously: Hold the button down. w The new value flashes while the settings are being made. w The actual temperature is displayed about 5 seconds after the last button is pressed.
Maintenance u Grasp the filter by the handle. u Turn it 90° to the right or left Fig. 5 (1). u Remove the filter . u Insert the new filter with the handle in a vertical position. u Turn it 90° to the right or left Fig. 5 (1) until it clicks into place. Fig. 5 6.2 Replacing the water filter The water filter should be changed when the Filter symbol Fig. 2 (10) lights up.
Maintenance WARNING Risk of injury or damage due to hot steam. Hot steam can cause scalding/burns and damage to surfaces. u Do not use steam cleaners. NOTICE Incorrect cleaning damages the appliance. u Do not use concentrated cleaning agents. u Do not use steel wool or sponges that scour or scratch. u Do not use caustic or abrasive cleaning materials or those containing sand, chloride, chemicals or acids. u Do not use chemical solvents.
Troubleshooting u Notify a qualified service provider, specifying the fault, appliance designation Fig. 8 (1), service no. Fig. 8 (2) and serial Fig. 8 (3) no. w This will help us to provide you with a faster and more accurate service. u Keep the appliance closed until the Customer Service engineer arrives. w The food will stay cool longer. u Disconnect the power plug (do not pull on the power cord to do this) or switch off the fuse. 6.
Troubleshooting Problem Possible Cause Correction A faint clicking sound The sound always occurs when the u The sound is normal. refrigeration unit (the motor) automatically switches on or off. A hum. It is briefly a little louder when the refrigeration unit (the motor) switches on. The refrigeration increases automati- u The sound is normal. cally when the SuperFrost function is activated, fresh food has just been placed in the appliance or the door has been left open for a while.
Troubleshooting Problem Possible Cause Correction The outside surfaces of the appliance are hot*. The heat of the refrigerant circuit is u This is normal. used to prevent condensate from forming. The IceMaker cannot be switched on. The appliance and therefore the u Connect the appliance (see Start-up). IceMaker are not connected. The IceMaker is not making ice cubes. The IceMaker is not switched on. u Switch the IceMaker on. The drawer of the IceMaker is not u Close the drawer properly.
Putting appliance out of service Problem Possible Cause Correction The door was open for longer than u The interior light automatically switches itself off if 15 minutes. the door has been open for about 15 minutes. The LED interior light is faulty or the cover is damaged WARNING Risk of injury from electrical shock. Live parts are under the cover. u The LED interior light should only be replaced or repaired by the Customer Service department or by engineers trained to do so.
Liebherr Warranty Plan WARNING Danger of electric shock. u Cut off the plug from the power cord and discard. u Cut off the power cord from the discarded appliance. Dispose of separately from the appliance. Ensure during and after disposal that the appliance isn't stored in the vicinity of gasoline or other flammable vapors and liquids.
For Service in the U.S.: Liebherr Service Center Toll Free: 1-866-LIEBHER or 1-866-543-2437 Service-appliances.us@liebherr.com PlusOne Solutions, Inc. 3501 Quadrangle Blvd, Suite 120 Orlando, FL 32817 For Service in Canada: Liebherr Service Center Toll Free: 1-888-LIEBHER or 1-888-543-2437 www.euro-parts.ca EURO-PARTS CANADA 39822 Belgrave Road Belgrave, Ontario, N0G 1E0 Phone: (519) 357-3320 Fax: (519) 357-1326 www.liebherr-appliances.com Part No.
