Specifications

adorneTM GUIDE SPECIFICATIONS
Project Name Project No. Date
Project Location 26 51 13.13-2 Under-Cabinet Lighting System
B. Store and handle in strict compliance with manufacturer’s written instructions and
recommendations.
C. Protect from damage due to weather, excessive temperature, and construction
operations.
PART 2 - PRODUCTS
2.1 MANUFACTURERS
A. Basis-of-Design Product: The design for under-cabinet lighting system components is
based on products manufactured by legrand
®
/adorne
™
, 60 Woodlawn Street, West
Hartford, CT 06110; toll-free 877-295-3472, telephone [phone], Web Site:
www.legrand.us/adorne.
B. Substitutions will be considered under provisions of Section 01 25 00.
2.2 UNDER-CABINET LIGHTING SYSTEM
Specifier Note: Retain as many of the following products as required for a specific project and
delete the others.
A. Under-Cabinet Lighting System: Modular, fully customizable system of components
that can be either hard-wired or plugged into any home wiring configuration. Designed
for use in kitchens, offices, hospitality, and healthcare applications.
B. Modular Tracks:
Specifier Note: Retain the type of modules required for a specific project and delete the others.
If a project requires multiple modules include a schedule at the end of this section.
1. 12" Modular Track: adorne
™
Part No. APMT12[TM2][W2]; 12-inch length
includes one (1) outlet module and one (1) blank module, [titanium] [white] color;
capable of supporting up to two (2) LED lights; provides 120V power via 15A
outlet modules and 20A pass-through; module openings on six (6) inch centers;
outlets are tamper resistant and ETL Listed.
2. 18" Modular Track: adorne
™
Part No. APMT18[TM4][W4]; 18-inch length
includes one (1) outlet module and one (1) blank module, [titanium] [white] color;
capable of supporting up to two (2) LED lights; provides 120V power via 15A
outlet modules and 20A pass-through; module openings on nine (9) inch centers;
outlets are tamper resistant and ETL Listed.
3. 27" Modular Track: adorne
™
Part No. APMT27[TM2][W2]; 27-inch length
includes two (2) outlet modules and one (1) blank module, [titanium] [white] color;
capable of supporting up to three (3) LED lights; provides 120V power via 15A
outlet modules and 20A pass-through; module openings on nine (9) inch centers;
outlets are tamper resistant and ETL Listed.
4. Short Modular Track: adorne
™
Part No. APST9[TM1][W1]; for use with narrow
single cabinets; back feed power from in-wall wiring; 10-1/4-inch length with end
caps, [titanium] [white] color; tamper resistant; ETL Listed.
5. 18" Modular Track Extender: adorne
™
Part No. APME18[TM2][W2]; 18-inch
length blank module enables a perfect fit in any room, [titanium] [white] color; cut
to length (minimum of six (6) inches); attach to end of modular track; does not
contain any module openings; ETL Listed.
6. Modular Track Corner Connector: adorne
™
Part No. APCC[TM4][W4]; use with
installations that include a right-angle corner to connect two (2) modular tracks,
