21.0 USER SETTING RECORD
PARAMETER MENU: USER SETTING RECORD
PARAM. PARAMETER FACTORY USER
NUMBER NAME DEFAULT SETTING
0 LINE VOLTS AUTO
 1 SPEED#1 20.00Hz
 2 SPEED#2 20.00Hz
 3 SPEED#3 20.00Hz
 4 SPEED#4 20.00Hz
 5 SKIP#1 .00Hz
 6 SKIP#2 .00Hz
 7 BANDWID 1.00Hz
8 ACCEL 30.0 SEC
9 DECEL 30.0 SEC
 10 MINFRQ .50Hz
 11 MAXFRQ 60.00Hz
12 DC BRAKE .0 VDC
13 DC TIME .0 SEC
14 DYN BRAKE OFF
16 CURRENT 180%
17 MOTOR OL 100%
 18 BASE 60.00Hz
 19 FXBOOST (NOTE1)
NOTE 1: REFER TO SECTION 18.0 - DESCRIPTION OF PARAMETERS.
