18.0 DESCRIPTION OF PARAMETERS
0 LINE VOLTS (LINEVOLTAGE)
This parameter calibrates the drive for the correct input voltage, and can be set to AUTO, HIGH, or LOW.
When set to AUTO, the drive measures the DC bus voltage when power is applied and automatically
calibratesitselfaccordingtothemeasuredvalue(DCbusvoltageisequaltoinputvoltagemultipliedby1.4).
 Thisparameter can also be set “manually”, using the HIGH orLOW settings. For actual line voltages
of230/240Vac(on240/200Vacmodels),460/480Vac(on480/400Vacmodels),or575/590Vac(on
590/480Vacmodels),setthisparametertoHIGH.AlsousetheHIGHsettingfor240/120Vacsinglephase
input models. Refer to the table below.
 Foractuallinevoltagesof200/208Vac(on240/200Vacmodels),380/415Vac(on480/400Vacmodels),
or460/480Vac(on590Vacmodels),setthisparametertoLOW.Refertothetablebelow.
INPUT LINE VOLTAGE SELECTION
RATED INPUT ACTUAL PARAMETER
INPUT VOLTAGE PHASE LINE VOLTAGE SETTING
240/120 VAC 1 230/240 VAC HIGH
240/120 VAC 1 115/120 VAC HIGH
240 VAC 1 230/240 VAC HIGH
240/200 VAC 3 230/240 VAC HIGH
240/200 VAC 3 200/208 VAC LOW
480/400 VAC 3 460/480 VAC HIGH
480/400 VAC 3 380/415 VAC LOW
590/480 VAC 3 575/590 VAC HIGH
590/480 VAC 3 460/480 VAC LOW
