User guide

50
PARAMETER MENU
PARAM. PARAMETER RANGE OF FACTORY
NUMBER NAME ADJUSTMENT DEFAULT
65 PROGRAM MAINTAIN, RESET 60,
   RESET50(NOTE4) RESET60
66 HISTORY MAINTAIN, CLEAR MAINTAIN
70 PID MODE OFF, NORMAL, REVERSE OFF
74 PID FB TB-5A, TB-5B TB-5A
75 FB @ MIN -32768 to 32767 0.0 %
76 FB @ MAX -32768 to 32767 100.00 %
77 P GAIN 0.0 - 999.9 % 5.0 %
78 I GAIN 0.0 - 10.0 SEC 0.0 SEC
79 D GAIN 0.0 - 10.0 SEC 0.0 SEC
80 PID ACC 0.0 - 100.0 SEC 30.0 SEC
81 MIN ALRM FB @ MIN - FB @ MAX 0.0 %
82 MAX ALRM FB @ MIN - FB @ MAX 0.0 %
98 LANGUAGE ENGLISH
 99 FAULTHISTORY (VIEW-ONLY) (N/A)
NOTE4:“RSTHIGH”WILLAPPEARONUNITSSETUPFORHIGHFREQUENCY.
NOTE!
If you are working with Software M108313 or earlier (see Parameter 63), parameters 69 and 70 are
shown here as parameters 98 and 99.
