NOTE 1: REFER TO SECTION 18.0 - DESCRIPTION OF PARAMETERS.
NOTE2:MAXLIMITIS650HzONUNITSWITHHIGHFREQUENCYSOFTWARE.
NOTE3:IFLINEVOLTSISSETTO“LOW”(ORSETTO“AUTO”ANDTHEINPUT
VOLTAGEISLOW),RANGEIS25-150%.
PARAMETER MENU
PARAM. PARAMETER RANGE OF FACTORY
NUMBER NAME ADJUSTMENT DEFAULT
*22 TORQUE CONSTANT, VARIABLE CONSTANT
CT/NO CMP
 23 CARRIER 2.5,6,8,10,12,14kHz 2.5kHz
25 START NORMAL, POWER-UP, NORMAL
AUTO RE-, RE-BRAKE
26 STOP RAMP, COAST COAST
27 ROTATION FORWARD, REVERSE, FORWARD
FWD&REV, FWD@LOC
28 AUTO/MAN AUTO, MANUAL, BOTH BOTH
29 MANUAL KEYPAD, 0-10 VDC KEYPAD
30 CONTROL LOCAL, REMOTE, BOTH LOCAL
31 UNITS HERTZ, RPM, % HZ, HERTZ
/SEC, /MIN, /HR, GPH, NONE
32 HZ MULT .10 - 650.0 1.00
33 SPEED DP XXXXX, XXX.X, XXXXX
XX.XX,X.XXX,.XXXX
34 LOAD MLT 95 - 139% 100%
35 CONTRAST LOW, MED, HIGH MED
 36 SLEEPTH .00-360.0Hz 0.00Hz
37 SLEEP DL 0.0 - 300.0 SEC 30.0 SEC
38 SLEEP BW FB @ MIN - FB @ MAX 0%
 39 TB5MIN .00-360.0Hz(NOTE2) 0.00Hz
 40 TB5MAX .00-360.0Hz60(NOTE2) 0.00Hz
41 AIN FLTR 0.01 - 10.0 SEC 0.02 SEC
42 TB10A OUT NONE, 0-10V, 2-10V NONE
