17.0 PARAMETER MENU
NOTE 1: REFER TO SECTION 18.0 - DESCRIPTION OF PARAMETERS.
NOTE2:MAXLIMITIS650HzONUNITSWITHHIGHFREQUENCYSOFTWARE.
NOTE3:IFLINEVOLTSISSETTO“LOW”(ORSETTO“AUTO”ANDTHEINPUT
VOLTAGEISLOW),RANGEIS25-150%.
PARAMETER MENU
PARAM. PARAMETER RANGE OF FACTORY
NUMBER NAME ADJUSTMENT DEFAULT
0 LINE VOLTS HIGH, LOW, AUTO AUTO
 1 SPEED#1 MINFRQ-MAXFRQ 20.00Hz
 2 SPEED#2 MINFRQ-MAXFRQ 20.00Hz
 3 SPEED#3 MINFRQ-MAXFRQ 20.00Hz
 4 SPEED#4 MINFRQ-MAXFRQ 20.00Hz
 5 SKIP#1 .00Hz-MAXFRQ 0.00Hz
 6 SKIP#2 .00Hz-MAXFRQ 0.00Hz
 7 BANDWID .00-10.00Hz 1.00Hz
8 ACCEL NOTE 1 30.0 SEC
9 DECEL NOTE 1 30.0 SEC
 10 MINFRQ .00-MAXFRQ 0.50Hz
 11 MAXFRQ MINFRQ-120.0HZ(NOTE2) 60.00Hz
12 DC BRAKE NOTE 1 0.0 VDC
13 DC TIME .0 - 999.9 SEC 0.0 SEC
14 DYN BRAKE OFF, ON OFF
 16 CURRENT 25-180%(NOTE3) 180%
17 MOTOR OL 25 - 100% 100%
 18 BASE 20.00-360.0Hz(NOTE2) 60.00Hz
19 FX BOOST .0 - 30.0% NOTE 1
20 AC BOOST .0 - 20.0% 0.0%
21 SLIP COMP .0 - 5.0% 0.0%
