direction. Therefore the interlocked delay time could potentially prevent it. Normally, the
interlocked delay time should be larger than the duration of crane stop.
Bypass EMS
“Bypass EMS” means that the relay relating to pushbutton will not be controlled by EMS
mushroom or emergency stop signal.
Control By EMS
“Control by EMS” means that the relay relating to pushbutton is controlled by EMS
mushroom or emergency stop signal.
ID-Code Remote Setting
ID Code Remote setting allows you to overwrite ID code of receiver when Receiver or
Transmitter is damaged. Before remote setting, one must make sure both TX and RX are in
same frequency channel. By using remote setting, receiver ID code will be overwriting by
the transmitter.
Note:
(1) All radios of same model within its radio operating distance, might be affecting by
ID code remote setting.
(2) Transmitter ID code remote setting overwrite the ID code of receiver only.
(3) Receiver will not accept ID code remote setting signal 4 minutes after main power
being turn ON.
Power Saving
Power Saving Mode: By using firmware to control frequency transmission cycle period, thus
to reduce power consumption of transmitter.
Note: the operating distance will be decreased when the “Power Saving” mode is activated.
Power-On Mode
“Any pushbutton Power-On mode”: The receiver will be “Power-On” once any
pushbutton on transmitter is pressed.
“Start pushbutton Power-On mode”: The receiver will be “Power-On” once Start
pushbuttons is pressed.
“E.U. (standard) Power-On mode”: The receiver will be “Power-On” once Start
pushbuttons is pressed. In case of the receiver is being turn off due to EMS button is pressed
or “Auto Off” due to idle time, one must switch the key to “OFF” position, then switch the
key to “ON” and Start position for re-start. EU Standard is based on “continuous
transmission” with “Auto Off” after 3 minutes of idle time.
“E.U. (simple) Power-On mode”: The receiver will be “Power-On” once Start button is
pressed. It’s not necessary to switch the key to off position before restarting the system due
to the idle time or EMS button is pressed.
Note: To Power-On the system, EMS button (mushroom) must be pull out and Start Key
must remain in ON position.
Transmit Mode
“Non-continuous transmitting mode”: After “Power-On”, the transmitter will transmitting
the signal only when the pushbutton is pressed. This mode can save the power of transmitter.
“Continuous transmitting mode”: Transmitter will continuously transmit signal once
transmitter is being Power-On.
Save Power
This function is used to turn off the Transmitter after a given idle time.
*Only available under “continuous transmitting” mode.
Auto-OFF(TX)
This function refers to turn off the Transmitter after a given idle time while transmitting the
signal to switch off the receiver main relay.
*Only available under “continuous transmitting” mode.
LED ON/OFF
“LED-OFF”:
LED indicator will remain OFF during normal operation to save
b
attery
power but it is still available for warning and fault indication.
“LED-ON”:
LED indicator will be lighten with green color when transmitting.
LED OFF-Time
This setting allows you to select the LED intermittent time
to save transmitter power. i.e.: If select 1 second is selected, the LED will be lighted every 1
second.
Passive Act
This function ensures safe operations, including when there are disturbances that may affect
the normal operating conditions. This assures that when the machine operates, the control is
not subject to temporary and unexpected stops. Possible short interferences are bypassed.
The passive act can be select in 2 mode as below,
“Ry Off” If the interferences are larger than the pre-set time, the receiver will turn off all the
relays under “NORMAL” function except the MAIN relay.
“Power-Off” If the interferences are lar
g
er than the
p
re-set time, the receiver will turn off
