The relative relay is “ON” when the pushbutton is pressed and held; and relay is “off” when
the pushbutton is released.
Toggle
Maintained function: the relay is operated by pressing and releasing; press and release again
to turn off the relay.
ON/OFF
Both pushbuttons are used to operate the same relay. Press the ON pushbutton to activate the
relay and press the OFF pushbutton to de-activate the relay.
Inching
Once pushbutton is pressed then the relative relay will be conducted within a certain time, in
order to operate with short and precision movement. Press and hold inching pushbutton and
press motion pushbutton to perform inching motion.
Interlock
The two pushbuttons are interlocked; it’s not possible to operate two opposite functions at
same time.
Non-Interlock
The two pushbuttons can be operated at the same time: When the application allows to
operate at the same time two functions which are usually opposite to one another.
Dual Motor
When 1
st
step pushbutton is pressed, the 1
st
step relay turns ON,if2ndstep is being pressed
then 2
nd
step relay turns ON and 1
st
step relay turns OFF. (For dual motor hoist)
Relay
Pushbutton
1
st
Step Relay 2
nd
Step Relay
1
st
Step ON OFF
2
nd
Step OFF ON
Dual Motor (1)
The main function characteristic of Dual Motor (1)
is same as Dual Motor except the 1
st
step relay will not be activated (bypass) while pushbutton is returning from 2
nd
step to 1
st
step.
Combination
When 2 buttons are being pressed simultaneously, it would result for an additional relay
output (as toggle) to suit some of the special application such as lighting system.(No any
extra pushbutton required to save the space and cost)
*Combination setting is prohibited for magnetic devices.
3 speeds
By pressing START button, it could control up to 3 speeds. Press the button till 2
nd
speed,
then press START button to turn on the 3
rd
step relay.
Digital 4S
By pressing START button, it simulate digital signal with the binary combination of relay
output to control the digital interface devices up to 4 speeds such as frequency inverter.
Relay
Pushbutton
UP 2
nd
Step
Relay
DW 2
n
d
Step
Relay
1
st
Speed Press UP 1
st
Step OFF OFF
2
nd
Speed Press UP 2
nd
Step OFF ON
3
rd
Speed
Press Start button 1 time
ON OFF
4
th
Speed
Press Start button 2 times
ON ON
Acceleration Delay Time
This function uses to set the time interval between acceleration relay (i.e. conduction-
delayed time of acceleration relay). It is suitable for accelerative operation only in order to
prevent the cranes directly runs to highest speed to damage the motor.
Interlock Delay Time
“Interlock Delay Time” is delay time between 2 opposite pushbuttons are being press one
after another. i.e.: while crane is moving one direction (forward), moving opposite direction
(backward) immediately would be dangerous specially when crane is hooking up the heavy
object. The object may sway if crane does not completely stop before moving into opposite
(Annex I) Definition of Function
Til
Note
: UP 1
st
step relay is
used for direction control.
Therefore UP 1
st
step relay
remain ON always when UP
button is being pressed.
