Owner's manual

IFB Receiver
SPECIFICATIONS AND FEATURES
Operating frequencies: 537.6 MHz to 862.0 MHz
Number of frequencies: 256 per block (using 26 MHz maximum wide band)
Channel spacing: 100 kHz (25 kHz programmable)
Frequency control: Crystal Controlled Phase Locked Loop
Sensitivity: 1 uv (20 dB SINAD)
Signal/Noise ratio: 95 dB A-weighted
Squelch quieting: 90 dB
AM rejection: 50 dB, 10 uv to 100 mv
Modulation acceptance: ±20 kHz
Spurious rejection: Greater than 70 dB
Third order intercept: 0 dBm
Frequency response: 100 Hz to 10 kHz, (±1db)
Pilot tone: 29.997 kHz, 4.5 kHz deviation (fixed crystal controlled)
Audio output, headphone: 1 Vrms into 50 ohms minimum
Antenna: Headphone cable
Programmable memory: 5 frequencies
Front panel controls: Single knob controls Audio Output Level, Power on, programming
and Scan Frequency Selection
Indicators: 1 red LED Indicator for power on, blinks to indicate channel number, blinks
fast during scan, and has short/long blinking for low battery.
Power requirement: Single 9V Alkaline Battery for approximately 8 hours operation.
Power consumption: 60 ma.
Weight: 7.3 oz with battery
Size: 3.6 x 2.4 x 0.8 inches (housing only, belt clip and
knob extend beyond the housing.)
Specifications subject to change without notice.
CE Compliance: ETS 300 445
Lectrosonics Model: IFB R5 FM Receiver
This product meets the CE Compliance Standards - ETS 300 445; January
1996. A copy of the Declaration of Conformity may be requested from your
dealer or by contacting the factory directly:
Lectrosonics, Inc.
Marketing Department
581 Laser Rd. NE, Rio Rancho, NM 87124 USA
tel: 505-892-4501 fax: 505-892-6243 e-mail:
marketing@lectrosonics.com
Rio Rancho, NM USA
