SPECIFICATIONS AND FEATURES

Operating frequencies: 169 to 172 MHz; 174 to 186 MHz

RF Power output: 50mW

Deviation: ±15kHz

Spurious radiation: 55dB below carrier

Equivalent input noise: -121dBV

Input

Types: 200 Ohm dynamic

5V phantom power

1k Ohm, 2-wire electret with 5 VDC positive bias

Level: Nominal 2mV to 300mV (before compression)

Impedance: 22k Ohms (compatible with all Lo-Z microphones)

Input compressor: Soft compressor, 30 dB range allows 3 Volt max. input

Gain control range: 43dB; semi-log rotary control

Controls: 2 position Power switch; Rotary knob adjusts audio gain

Connector: 3-pin XLR type with locking collar

Battery: Any 9 Volt alkaline battery

Weight: 7 ozs. including battery

Dimensions: 1.5 x 1.5 x 4.2 inches

Emission designator: 40K0F3E

Specifications subject to change without notice
