screen saver mode. Time length options include 1min , 2min,
5min, 10min, 15min, 30min, 1hour, 2hour, 5hour and Off. Of
course, selecting Off keeps the oscilloscope from entering screen
saver mode entirely.
2. Pressing the Date/Time option button shows the Date/Time menu
where you can make this setting and choose to show it on the
lower-right of your display. For more information, see Setting and
Displaying the Date/Time (on page 100).
3. Press the Quick-Cal option button to turn quick calibration On or
Off.
4. Press the USB Speed option button to select from Full or High
Speed transfer options for the Back USB connector. See, Back and
Side Connections (on page 10) for more information.
5. Press the Next Page option button to display page 1/4.
Print Setup
PLEASE NOTE THE FOLLOWING:
 As explained in Utility Menu (on page 79), only when the Back
USB option button is set to Printer is the Print Setup... option
button enabled for use.
 Your printer may override these setup selections to ensure the
best fit. If selections are not supported by your printer, the
oscilloscope uses the Default setting.
 Most USB printers supporting direct printing through Type A USB
port connections are compatible with your WaveAce oscilloscope.
Refer to your printer's product documentation to verify
compatibility.
Print - Page 1/2
After pressing the enabled Print Setup option button, the first of two
PRINT menus (Page 1/2) is shown and contains the following option
button controls.
