WaveAce 1000/2000
Menu
Option
Default
REF
Type
Waveform
Source
CH1
Menu
Option
Default
TRIGGER (Edge)
Type
Edge
Source
CH1
Slope
Rising
Mode
Auto
Coupling
DC
Level
0.00V
Menu
Option
Default
TRIGGER (Pulse)
Type
Pulse
Source
CH1
When
=
Set Pulse Width
1.00ms
Mode
Auto
Coupling
DC
Menu
Option
Default
TRIGGER (Video)
Type
Video
Source
CH1
Polarity
Normal
Sync
All Lines
