3. Recall the waveform either from your Device (meaning internal
memory on your WaveAce) or from a File (stored on a USB
memory device) using the following methods.
Recalling Waveforms from Internal Memory
 Press the Save To option button to select Device.
 Press the Waveform option button or turn the Universal
front panel knob to select the number (No. 1 - No. 20)
assigned to the waveform you want to recall.
 Press the Recall option button and the selected Waveform
is recalled from internal memory. The oscilloscope briefly
shows a Read Data Success! message on the lower part of
the grid display area.
Recalling Waveforms from a USB Memory Device
 Insert the USB memory device and press the Save To option
button to select File.
 Press the Recall option button and the SAVE ALL screen is
shown. See Using the SAVE ALL Screen (on page 76) to
continue recalling from your USB memory device.
Saving and Printing Waveform Pictures
You can save a waveform image (.BMP) file to a USB memory device or
print a waveform image directly to a USB-connected printer from your
WaveAce.
Once you have set up your print options as explained in Print Setup (on
page 88) and connected the device to the USB port, you can press the
Print front panel button to either Save or Print the image.
Note: Most USB printers supporting direct printing through Type A USB port
connections are compatible with your WaveAce oscilloscope. Refer to your
printer's product documentation to verify compatibility.
1. Press the Save/Recall front panel button and the SAVE/REC menu
is shown.
2. Use the Type option button and select Picture.
