User manual

WaveAce 1000/2000
WA1K2K-OM-E RevB 63
 Insert the USB memory device, press the Save To option
button and select File.
 Press the Save option button and the SAVE ALL screen
opens showing Directorys by default. Finish saving your
setup using the following instructions in Using the SAVE ALL
Screen (on page 74).
1. Switch to the SAVE ALL - Files Menu - covered in the
Using the SAVE ALL Screen (on page 74) topic.
2. Name and Confirm your file using the steps explained
in Creating Folders and Files - also covered in the
Using the SAVE ALL Screen (on page 74) topic.
Recalling Setups
1. If you're not already on the SAVE/REC menu, press the
Save/Recall front panel button and the SAVE/REC menu is shown.
2. Press the Type option button and select Setups.
3. Recall your setup either from your Device (meaning internal
memory on your WaveAce) or from a File (stored on a USB
memory device) using the following methods.
Recalling Setups from Internal Memory
 Press the Save To option button to select Device.
 Press the Setup... option button or turn the Adjust front
panel knob to select the number (No. 1 - No. 20) assigned
to the setup you want to recall.
 Press the Recall option button and the selected Setup is
recalled from internal memory. The oscilloscope briefly
