 With either Save or Print Picture chosen from the Print Key option
button (and corresponding options setup as explained in Print
Setup (on page 88)), simply press the Print front panel button to
instantly execute your selected function.
 The Recall option is excluded from Save/Recall menus when
Picture or CSV is selected as the Type.
 The Load option is disabled (grayed-out) on menus inside the
SAVE ALL screen when Pictures or CSV file types are selected as
Type.
Saving Data as a .CSV File
You can save waveform data as a comma-separated value (.CSV) file. You
can then use this information in other applications, such as Microsoft
Excel. The .CSV file contains the data points (horizontal and vertical
information) of the displayed waveform. You can also choose to save
these parameters to the .CSV file:
 Record Length
 Sample Interval
 Trigger Point
 Vertical Units
 Vertical Scale
 Vertical Offset
 Horizontal Units
 Horizontal Scale
 Model Number
 Serial Number
 Software Version
1. Press the Save/Recall front panel button. The SAVE/REC menu
opens.
