Datasheet

SPECIFICATIONS AND ORDERING INFORMATION
SPECIFICATIONS AND ORDERING INFORMATION
7
Specifications LogicStudio 16
Input Channels 16
Sample Rate 1 GS/s on 8 Ch, 500 MS/s on 16 Ch
Minimum Detectable Pulse Width 3.75 ns
Memory 40 kpts on 8 Ch, 20 kpts on 16 Ch
Trigger Types Edge, pattern, pulse width, pattern width. I
2
C, SPI, UART
Threshold Selections TTL, CMOS (1.8 V, 2.5 V, 3.3 V, 5 V), User defined
User-defined Threshold Range 0–7 V
Maximum Survivable Input Voltage ±40 VDC
Threshold Accuracy ±150 mV + 5% of threshold
Maximum Input Dynamic Range 40 V
p-p
Minimum Voltage Swing 500 mV
p-p
Input Impedance 150 kΩ parallel 12 pF
Channel-to-Channel Skew 1 ns typical
Trigger Resolution 500 MS/s
Host Port USB 2.0, bus-powered peripheral
Size 3.2" x 4.9" x 1.1" (81.3 mm x 124.5 mm x 28.0 mm)
Ordering Information
Product Description Product Code
16 Channel, 1 GS/s, 100 MHz USB Logic Analyzer LogicStudio 16
Customer Service
LeCroy oscilloscopes and probes are designed, built, and tested to ensure high reliability. In the unlikely event you experience
difficulties, our digital oscilloscopes are fully warranted for three years and our probes are warranted for one year.
This warranty includes:
• No charge for return shipping • Long-term 7-year support • Upgrade to latest software at no charge
