5. Trigger Modes
Oscilloscope trigger modes of
Auto, Normal and Single help ensure
what you need to see is always on
the display.
6. Save and Recall
Save screenshots to share with
others or save waveforms and
setups for recalling later.
7. Add/Remove/Hide
Waveforms
One click to add a new waveform,
one click to remove it, right-click
to hide it for later viewing.
8. Waveform Display
and Scaling
View waveforms stacked on top of
each other or overlay one waveform
on top of another. Change the vertical
scale by dragging the bottom edge.
9. Built-in Help and Support
Not sure how to use a certain tool,
mouse over for tool tips or access the
manual from the Help menu. Have a
question or suggestion? Click on Tell
LeCroy in the Help menu and send
an email directly to LeCroy with the
waveforms, screen capture and setup
file attached to the message.
