U5010W
Introduction Thank you for buying this high quality appliance! This handbook is designed to help you through each step of owning your new appliance, from installation, to use. Please read through all of this guide carefully before you start using your appliance, as we have endeavoured to answer as many questions as possible, and provide you with as much support as we can.
Contents For your safety .......................................................................................................... 1 About your product .................................................................................................... 3 Installing your appliance............................................... 4 Using your appliance................................................. 5 Care& cleanin 8 Troubleshooting.....................................................
For Your Safety Disposal of old appliances Before disposin g of an old appliance , make sure that you have broken off, or disabled any locking mechanism s to preven t children becomin g accidentall y locked inside. Remov e any plugs and power leads to ensure that the applianc e is inoperative. Please note: This symbol means that products bearing it may not be dispose d of with household waste. The refrigeration system contain s insulatin g gases and refrigeran t which will require specialis t disposal .
For Your Safety Warning: Do not allow the refrigerant circuit to become damaged while using or installing. Should it become damaged, do not use the appliance until you are instructed to do so by a service engineer. Refrigerant can ignite or cause damage to the eye when leaking. Always remember to unplug the appliance before cleaning. When disconnecting from the electricity supply, pull the plug, not thepowe r cord.
U5010W MODEL Width(mm) U5010W 501 Technical Data 540 Height(mm) 845 Net volume(litres) 0L/70L Energy Rating A+ Freezing capacity 4kg/24hrs Climate Class ST Noise(dB(A)re1pw) Refrigerant type 40dBA R600a (33g)
25mm 25mm
Using Your Appliance About the thermostat • The thermostat is located in the upper Front part of the appliance. • To reduce the temperature inside the appliance, turn the thermostat towards 4 maximum. • To increase the temperature inside the appliance turn the thermostat towards 1 minimum. • Depending on the ambient temperature of the room the appliance is in, you may need to adjust the thermostat accordingly.
Using Your Appliance Tips for using this appliance • Before storing cooked foods in the refrigerator, allow them to cool to room temperature. • To maintain adequate air circulation, do not over fill the appliance. If there is too much food inside, the compressor does not work as effectively. • Do not open the door any more than necessary - this will keep the temperature as cold as possible inside. • When storing frozen food in the freezer, make sure that you follow the food manufacturers guidelines.
In the event of a power cut If the power failure is 3 hours or less, food can remain inside the appliance. Keep the door closed to maintain the temperature inside. If the power cut is longer than 3 hours, remove all food, wrap well and store in a cool dry place. Important: Be aware that the storage life of the food will have been reduced. Use up this food as soon as possible or discard. Do not re-freeze food which has thawed, either consume or cook and re-freeze if appropriate.
Care & Cleaning Before cleaning your appliance You should always unplug this appliance before cleaning. To clean your appliance • Once defrosted, remove the accessories inside and clean the using warm water and a neutral detergent. Do not place them in a dishwasher. • Clean the inside of the cabinet with warm water and a neutral detergent, do not use harsh abrasives or caustic cleaners. • Dry the inside of the cabinet with a soft, dry cloth.
Troubleshooting Before calling Lec Customer Care, please check the table below to see if the problem can be solved without calling for a Service engineer. Problem I Solution The fridge / freezer doesn't work • Check that the appliance is switched on • Check that the plug is not damaged • Check that the fuse has not blown • Check that the voltage is correct for the appliance • Turn the thermostat up higher • Check there has not been a power cut by checking the household lights.
Reversing the door FOR: The doors on the U5010W 4.Unscrew the three scews on the down hinge and screw them on the opposite side. 1.Unscrew the top cover and take off it. 2 screws for fixing the top cover 2.Unscrew the top hinge. 3 screws for fixing top hinge 5.Move the adjustable foot to the opposite side. 3.Re-install the top hinge pin,shaft sheath and block piece on the oppolsite side. a:Move the top hinge to opposite side 6.Align the door properly, fix the top hinge and top cover.
Changing the Plug 11 Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. This appliance must be earthed. The manufacturer declines any liability should these safety measures not be observed. Electrical Requirements Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance rating plate. The appliance is supplied with a 13 amp plug fitted.
Service Record 12 Please record your model number and serial number in the space below. Having these numbers to hand will help us to help you, quickly and more efficiently.
Lec Refrigeration Stoney Lane, Prescot, Merseyside, L35 2XW Customer Care Centre: 0844 815 3737 www.lec.co.uk Lec Refrigeration, a division of Glen Dimplex Home Appliances 08 26362 00 © 05.2006 4577672200 07.06.
