2. DB-4 connection to the Digital-Command-Station or to other
Booster:
The galvanic separated boosterbus connections enables the application of the
DigitalBooster DB-4 in connection with several command stations by using the 5-
poles Boosterbus, the CDE-Boosterbus or the Roco-Boosterbus.
The DB-4 is no Booster-Adapter. A change of the bus-system is impossible. The
booster-bus used for the connection of the first DB-4 to the digital command
station has to be used furthermore.
The below table indicates the possible connections to the available command
station.
5-poles
Boosterbus
CDE-
Boosterbus
Roco-
Boosterbus
Control Unit X
Central Station 1 X X
Central Station 2 X
Mobile Station 2 with Track Box X
ECoS 1 (50 000) X X
ECoS 2 (50 200) X X
Intellibox 1 X X
IB-Basic X
IB-COM X
Intellibox 2 X X
EasyControl X X
DiCoStation X
KeyCommander X
TWIN-CENTER X X
Roco 10761 (multiMAUS) X
Roco 10764 (multiMAUS) X
Fleischmann 680801 (multiMAUS) X
Roco / Fleischmann
multiZENTRALEpro
X
Roco / Fleischmann z21 and Z21 X
Lenz Digital plus LZ100 X
Lenz Digital plus LZV200 X
Viessmann Commander X X
2.1. DB-4 connection via the 5-poles Boosterbus:
The DigitalBooster DB-4 can be connected by use of the 5-poles boosterbus cable
(order code: Kabel Booster 1m, Part-No.: 000123), to one of the command stations
as per above table or to other boosters (e.g. DB-4, DB-2, 6015, 6017, Power 2, Power
3). The first booster shall be always connected to the command station by use of a 5-
poles boosterbus cable. The second booster shall be connected to the first one and so
on.
