User Manual

3
Connect the fixture to a suitable ground in accordance
with local electrical codes.
Connect one fixture wire to the neutral power line wire
with a wire nut.
Connect the other fixture wire to the hot power line
wire with a wire nut.
Mount the fixture by sliding it back onto the mounting
plate and re-installing the mounting plate screws
(reversal of figure 1A).
3A
1
2
3
4
1
3
2
Install the Fixture
Push the new lamp firmly all the way into the socket.
NOTE: Use only your fingers and a soft cloth to install
Use Volt, type T4, G9 baseMAX 60120 Watt
bi-pin halogen lamp.
Install the Lamp
1
4A
1
SOCKET
LAMP
