Instructions / Assembly

ManualsBrandsLAUREL CANYON ManualsOutdoor Heating39 in. Tall 11,000 BTU Portable Outdoor Propane Table Top Patio Heater, Quick Pulse Ignition, Auto Shut Off, Black

1

2

3

4

5

6

7

8

9

7

STEP 4

4-1. Fix 3 pcs Pins of 60mm length to

the Emitter Screen with 3 pcs Flange

Nuts then tighten them.

STEP 5

5-1. Put the Emitter Screen on the Burner.

5-2. Use 4 pcs 3/16” Bolts to connect the

Emitter Screen to the Burner. Tighten the Bolts.

STEP 6

6-1. Put the Guard on the Burner through

the Emitter Screen.

6-2. Put the ends of the Guard into the

holes of the Burner.

STEP 7

7-1. Put 3 pcs Washers on each Pins of the

60mm length.
