Instructions / Assembly

NOTE:PLEASE READ THE FOLLOWING SAFETY RULES.
The valve outlet must be maintained in good condition.
All gas connections should be checked for leaks utilizing a soap solution.
Never use a flame for the purpose.
A leak test should be performed with soapy water
Whenever connecing a new cylinder. Never use a match to test for leaks. If disassembly is required, a leak test should be
performed with soapy water upon reassembly.
The heater is designed to operate with a standard 1 Lbs. propane cylinder with approved cylinder connec
tion.
The gas manifold supply pressure must be regulated at 11 inches water column utilizing an approved regulator.
The minimum inlet gas supply pressure for the purpose of input adjustment is 8 inches water column. The maximum inlet gas
supply pressure 13 inches water column.
(1). The cylinder supply system must be arranged for vapor withdrawal.
(2). The cylinder used must include a collar to protect the cylinder valve
only cylinders marked “propane” must be used.
Save these instructions! Retain in a safe place for future reference.
5
ASSEMBLY
Warning:
1.Do not store a spare LP-gas cylinder under or near
this appliance
2.Never fill the cylinder beyond 80 percent full
Warning:
LP-gas supply cylinder to be used must be:
1. Constructed and marked in accordance with the
specifications for LP-gas cylinders of the U.S.
Department of transportation (DOT); or the standard for
cylinders, spheres, and tubes for transportation of
dangerous goods and commission, CAN/CSA-B339,as
appliance;
2. Provided with a listed overfilling prevention device; and
3. Provided with a cylinder connection device compatible
with the connection for the appliance.
