operation manual

Text: SCL
09
AutoCross-Laser 3C
Function / Application
Cross-line laser vertical and horizontal alignment
– The pivoted housing can be turned with a vernier adjustment mechanism
to permit exact positioning of laser lines.
– Adjustable feet with removable rubber caps
– Automatic levelling range 2.5°, accuracy 2 mm / 10 m
– A simple, precise plumb function is afforded by the additional plumb laser
at the bottom and the laser cross at the top.
– The vertical lines are aligned at right angles to one another.
General safety instructions
– Attention: Do not look into the direct or reected beam.
– The laser may not get into the hands of children!
– Do not point the laser beam towards persons.
– If a person‘s eyes are exposed to class 2 laser radiation, they should shut
their eyes and immediately move away from the beam.
– Do not expose the device to mechanical stress, extreme temperatures,
moisture or signicant vibration.
– The device must only be used in accordance with its intended purpose
and within the scope of the specications. Modications or changes to the
device are not permitted, this will otherwise invalidate the approval and
safety specications.
Laser radiation!
Do not stare into the beam!
Class 2 laser
< 1 mW · 635-650 nm
EN 60825-1:2014
Read the operating instructions and the enclosed brochure „Guarantee
and additional notices“ completely. Follow the instructions they contain.
This document must be kept in a safe place and if the laser device is
passed on, this document must be passed on with it.
!
