AutoCross-Laser 3C
For transport, the device must
always be switched off with the
transport securing device (2) so
as to protect device from damage.
!
1 Laser emitting window
2 ON / OFF switch;
Transport fastener
3 Vernier adjustment
4 5/8” thread (bottom)
5 Window for plumb laser (bottom)
6 Adjustable feet with
removable rubber caps
7 Tripod adapter
8 Vial for approximate alignment /
Low bat. display: Low battery
charge when bubble level flashes
9 Rechargeable battery
compartment (ACL 3C Pro) /
Battery compartment (ACL 3C Plus)
10 Hand receiver mode
11 Horizontal laser lines
12 Vertical laser line
