Part #: BLG-LED-4A (50325)
Specifications / Additional Information
BLG-LED-4 Blasting Gun Light Approvals
Lamp Type: LED Intrinsically Safe - Zone Zero Rating
Dimensions: Light Only- 7.125" X 4" X 3" ATEX II1GD Exia IIC T4 iaD T135C
Watts: 4 Class 1, Division 1 Groups A,B,C,D
LED Life Expectancy: 30,000 hours Class II, Division 1 Groups E,F,G
Lumens: 90 T4 temperature rating
Lighting Configuration: Spot Watertight
Mounting: Clamp on Blasting Gun Mount
Hazardous Location Classifications
Lens: Quick Change Tempered Glass
Lux: 145,400 @ lens - 599 @ 10'
Burn Time: 80hs Special Orders- Requirements
Power: Three AA Batteries Contact us for special requirements
Toll Free: 1-800-369-6671
U.L Approval: U.S. Explosion Proof Standards Intl: 1-903-498-3363
Lenses: 3 Lenses - Glass or Polycarbonate E-mail: [e-mail]
*Blasting Gun Not Included
