Part #: RL-85-5W1-UV365 (68977)
Lithium Ion Reliability: This pistol grip UV spotlight contains an integral lithium ion battery pack for the highest reliability and durability. This unit
charges in 2.5 hours and provides 16 hours of runtime when fully charged. The lithium ion batteries used in this unit do not require special
charging practices to preserve their effectiveness or longevity and can be recharged when only halfway depleted or only charged to a fraction of
their full capacity and will not suffer from degradation or battery memory issues. This means you do not need to wait until the batteries are fully
depleted before recharging them, nor do you need to allow them to fully recharge before using the unit. These batteries hold their charge for up
to 12 months, allowing users to avoid the need for constant maintenance charging.
The included universal smart charging unit is compatible with any voltages both domestic and international and plugs into any standard wall
outlet. The smart charger that ships with this light operates automatically and will top off the battery and quit once the battery is fully charged,
even if the light is left connected to the charger once fully charged.
Durability-Convenience: The RL-85-5W1-UV365 Ultraviolet LED Pistol Grip Spotlight contains a single ultraviolet LED that is fully potted within
a machined aluminum lamp housing and protected by a thick Lexan lens. This LED has an expected life span of 50,000+ hours and the entire
LED lamp housing can be removed and replaced. This light is constructed of UV, water and impact resistant materials including a handle
constructed of high impact nylon for extreme durability and resistance to damage from vibrations, shocks and impacts. The machined aluminum
lamp housing is finished with an anodized coating for corrosion resistance.
Versatility: The entire unit weighs only 14 ounces and comes with an included wrist lanyard for added carrying security. This light has a 3/8-16
inch brass nut fastener imbedded in the base of the handle to allow mounting this light to a tripod or magnetic base like our MM-2 or MM-5. We
also offer permanent mount bases, which can be screwed into the handle as well. This unit is fully field serviceable and requires no tools to
disassemble or reassemble. This unit is ideal for industrial and commercial testing applications as well as military, security and law enforcement
use.
Specifications / Additional Information
RL-85-5W1-UV365 Spotlight
Lamp Type: UltravioletLED
Dimensions: 4.5"-L 1.5"-Depth 5/8" W
Weight: 14.Oz
Watts: 5 watts
Voltage: Rechargeable- Universal Smart Charger
Materials: Aluminum - High Impact Nylon
Lamp Life Expectancy: 50,000 Hours
Battery: Lithium Ion
Charge Time: 2.5 Hours
Light Color: Ultraviolet, 365NM Special Orders- Requirements
Beam Type: Spot Contact us for special requirements
