Specification Sheet

Page: 3
Larson Electronics LLC www.LarsonElectronics.com
9419 E US HWY 175, Kemp, TX 75143 Phone: [phone] Fax: [phone] Email: [e-mail]
Part #: LEDLB-20E-IR (47103)
Links (Click on the below items to view):
- SpecSheet French
- SpecSheet Arabic
- Manual
- SpectrumChart
Specifications / Additional Information
LEDLB-20E-IR LED Light Bar LEDLB LED Features
LEDs: 20 Edixeon® 3 Watt IR LED Emitters Edixeon® 3 Watt IR LED Emitters
Dimensions: 12"-L 3"-H 3.57"-D LEDs Driven At 80%
Watts: 60 -40 C~ +80C Operating Temp Range
Voltage: 9-42 VDC
Spot Beam: 800'L x 80'W
Flood Beam: 250'L x 250'W
RoHS Compliant
Weight: 6.4 Lbs 70% Lumen Retention @65,000 hours
Lighting Configuration: 10° Spot or 35° Flood LED Chip Op Temp -40C to +110C
Mounting: Stud IP68 Rated Waterproof to 3ft
Wiring: Deutsch IPD / LADD DT04-2P connector
Amps: 5 (on 12 volts) 2.5 (on 24 volts)
Lumens: 3600 Special Orders- Requirements
Wavelength: 750Nm, 850Nm or 940Nm Contact us for special requirements
LED Life Expectancy: 50,000 hours Toll Free: 1-800-369-6671
Optics Efficiency: 90% Intl: 1-903-498-3363
Materials: Aluminum Housing, Polycarbonate Lens E-mail: [e-mail]
Housing Colors: Black or White
CE Certified
3 year warranty replacement on this LED light. After 30 days, the
customer ships the failed LED light and/or LED bulb to Larson
Electronics at their expense. If the failure is a manufacturer defect, we
will ship a new replacement to the customer. If failure occurs within 30
days of receipt, Larson Electronics will provide a return label via email
to the customer. When the failed light is returned, Larson Electronics
will ship a new replacement.
