11: Advanced Settings
EDS Device Servers User Guide 119
Configuration Record: Export System Configuration Page
XML Configuration
Record: Export System
Configuration Page
Settings
Description
Export XCR data to browser Select this option to export the XCR data to a Web
browser.
Export XCR data to the
filesystem
Select this option to export the XCR data to a
filesystem. If you select this option, enter a file name for
the XML configuration record.
Groups to Export Check the configuration groups that are to be exported
to the XML configuration record. If no groups are
checked, all groups will be exported.
XML Status Record: Export System Status
If you click XML Status Record at the top of an XML page, the XML Status Record:
Export System Status page displays. Here you can export the current system status in
XML format. The XML data can be exported to the browser window or to a file on the
filesystem.
Figure 11-6. XML Status Record: Export System Status Page
