Datasheet

LANCOM L-54ag Wireless
Management
LANconfig Configuration program for Microsoft Windows, incl. convenient Setup Wizards. Optional group configuration, simultaneous
remote configuration and management of multiple devices over IP connection (HTTPS, HTTP, TFTP)
LANmonitor Monitoring application for Microsoft Windows for (remote) surveillance and logging of the status of LANCOM devices and
connections, incl. PING diagnosis
WLANmonitor Monitoring application for Microsoft Windows for the visualization and monitoring of LANCOM WLAN installations, incl. Rogue
AP and Rogue Client visualization
Webconfig Integrated web server for the configuration of LANCOM devices via Internet browsers with HTTPS or HTTP
Access rights Individual access and function rights for up to 16 administrators
User administration RADIUS user administration for dial-in access (PPP/PPTP and ISDN CLIP)
Remote maintenance Remote configuration with Telnet/SSL, SSH (with password or certificate), browser (HTTP/HTTPS), TFTP or SNMP, firmware upload
via HTTP/HTTPS or TFTP
Security Access rights (read/Write) over WAN, LAN or WLAN can be set up separately (VPN only, Telnet/SSL, SSH, SNMP, HTTPS/HTTP),
access control list
Scripting Scripting function for batch-programming of all command-line parameters and for transferring (partial) configurations,
irrespective of software versions and device types, incl. test mode for parameter changes
SNMP SNMP management via SNMP V2, private MIB exportable by WEBconfig, MIB II
Timed control Scheduled control of parameters and actions (e.g. firewall rules or connection establishment) with CRON service
TFTP TFTP client and server with variable file names (name, MAC/IP address, serial number)
Diagnosis Extensive LOG and TRACE options, PING and TRACEROUTE for checking connections, LANmonitor status display, internal logging
buffer for SYSLOG and firewall events, monitor mode for Ethernet ports
AirWave Supported by the LANCOM Enterprise Management System (AirWave AMP, Site Planner, RAPIDS, Client)
Statistics
Statistics Extensive Ethernet, IP and DNS statistics; SYSLOG error counter
Accounting Connection time, online time, transfer volumes per station. Snapshot function for regular read-out of values at the end of a
billing period.
Export Accounting information exportable via LANmonitor and SYSLOG
Hardware
Power supply 12 V AC, external power adapter (230 V)
Power supply Via Power over Ethernet complaint with IEEE802.3af
Environment Temperature range 0-50 ºhumidity 0-95 %; non-condensing
Housing Robust synthetic housing, rear connectors, ready for wall mounting, Kensington lock; measures 210 x 45 x 140 mm (W x H x D)
Power consumption (max) ca. 4.5 Watts
Declarations of conformity
CE EN 55022, EN 301 489-1, EN 301 489-17, EN 60950
2.4 GHz WLAN ETS 300 328
5 GHz WLAN EN 301 893
Medical Medical conformity with EN 60601-1-2
Notifications Certifications notified in Germany, Belgium, Netherlands, Luxembourg, Austria, Switzerland, UK, Italy, Spain, France, Portugal,
Czech Republic, Denmark, Malta
Package content
Manual Printed User Manual (DE, EN) and Quick Installation Guide (DE/EN/FR/ES/IT/PT/NL)
CD CD with firmware, management software (LANconfig, LANmonitor, LANCAPI) and documentation
Cable Serial configuration cable, 1.5m
Cable 1 Ethernet cable, 3m
Antennas Two 3-dBi dipole dualband antennas
Power supply unit 12 V AC, external power adapter (230 V)
Support
Warranty 3 years, support via Hotline and Internet KnowledgeBase
Software updates Regular free updates (LCOS operating system and management tools) via Internet
