User Manual

ESS Audio/Modem Combo Card
Page - 8
3.3.4. Checking the Modem Installation Under Windows 95
1.) Click on the “Start” button on the taskbar.
2.) Select “Settings” and open the “Control Panel”.
3.) Double-click on the “Modem” icon.
4.) Click on the “Diagnostics” tap.
5.) Select the COM port that the modem “ESS ES56CV-PI Data Fax Voice Modem”
has been assigned to.
6.) Click on “More Info”.
If everything has been installed correctly, the following commands and their
results are displayed, “ATI1, ATI2, ATI3, ATI4, ATI5, ATI6, ATI7, AT+FCLA”
