User's Manual

YMF744 PCI Sound Card Hardware Configuration
Page -
4
2.1 Connectors for “YMF744/754 N6x”
2.1.1 External Connectors:
J1:......................
∅
3.5mm Phone Jack for
LINE IN
J2:......................
∅
3.5mm Phone Jack for
MIC IN
J3:......................
∅
3.5mm Phone Jack for
FRONT OUT
J4:......................
∅
3.5mm Phone Jack for
REAR OUT
J5:......................Connector for
MIDI/JOYSTICK
2.1.2 Internal Connectors:
J6:......................Internal connector for
LINE IN
(optional)
J7:......................Internal connector for
MIC IN
(optional)
J8:......................Internal connector for
FRONT OUT
(optional)
J9:......................Internal connector for
REAR OUT
(optional)
J10:....................Connector for
CD AUDIO IN
(Base Pin)
J11:....................Connector for
CD AUDIO IN
(JST)
J12:....................Connector for
AUX IN.
J13:....................Connector for
TAD/VOICE MODEM.
J14:....................Connector for
VIDEO IN.
J16:....................Connector for
PC/PCI Legacy Audio SIDEBAND SIGNAL.
J19:....................Connector for
PC-BEEP
(optional)
J20:....................Connector for
SPDIF IN/OUT
(optional)
CN3:...................Extension connector for
6-Channel AUDIO
(optional)
