1.6. Connectors for “YMF724 D10”
“YMF724 D10” includes up to seven internal connectors, four external Jack Ports, one
external MIDI/ Joystick connector, one VIDEO connector, one TAD/VOICE Modem connector,
one SPDIF, and one PC/PCI Legacy AUDIO SIDEBAND SIGNAL connector.
1.6.1. External Connectors:
J1:..........................
∅
3.5mm Phone Jack for
LINE IN
J2:..........................
∅
3.5mm Phone Jack for
MIC IN
J3:..........................
∅
3.5mm Phone Jack for
LINE OUT
J4:..........................
∅
3.5mm Phone Jack for
SPEAKER OUT
J5:.......................... Connector for
MIDI/JOYSTICK
1.6.2. Internal Connectors:
J6:.......................... Internal connector for
LINE IN
(optional)
J7:.......................... Internal connector for
MIC IN
(optional)
J8:.......................... Internal connector for
LINE OUT
(optional)
J9:.......................... Internal connector for
SPEAKER OUT
(optional)
J10:........................ Connector for
CD AUDIO IN
(ATAPI)
J11:........................ Connector for
CD AUDIO IN
(JST)
J12:........................ Connector for
AUX IN
J13:........................ Connector for
TAD/VOICE MODEM
J14:........................ Connector for
VIDEO IN
J15:........................ Connector for
SPDIF
(optional)
J16:........................ Connector for
PC/PCI Legacy Audio SIDEBAND SIGNAL
