1.8.4. Internal Connectors For “YMF724 J81”:
J6:......................Internal connector for
LINE IN
(optional)
J7:......................Internal connector for
MIC IN
(optional)
J8:......................Internal connector for
AUDIO OUT
(optional)
J10:....................Connector for
CD AUDIO IN
(ATAPI)
J11:....................Connector for
CD AUDIO IN
(JST)
J12:....................Connector for
AUX IN
J13:....................Connector for
TAD/VOICE MODEM
J14:....................Connector for
VIDEO IN
J16:....................Connector for
PC/PCI Legacy Audio SIDEBAND SIGNAL
J19:....................Connector for
PC-BEEP
(optional)
CN3:...................Extension connector for
6-Channel AUDIO
(optional)
JP1:....................Jumper for switching between
LINE OUT/SPEAKER OUT
