Appendix A: Protector XLE Components
Product Service 1-800-522-7658
33
Item Quantity Part No. Description
8A 1 9721901 Lamp, Fluorescent (T8 x 3') – use on 4' & 8' Hoods – NOT SHOWN
8B 1 9721900 Lamp, Fluorescent (T8 x 4') – use on 5', 6' & 7' Hoods – NOT SHOWN
10A 1 1302300 Switch, Rocker
11A 1 9818400 Access Cover
11B 1 9825100 Label, Access Cover (includes all three corner labels)
12B 1 9810801 Side Panel, 30" internal deep hoods
12D 4 1916400 Nut, Retainer #10-24
12E 4 1885512 Screw, Machine #10-24 x .75 Truss Head Stainless
13A 1 9951000 Air Foil 4' Assembly with trough
13B 1 9951001 Air Foil 5' Assembly with trough
13C 1 9951002 Air Foil 6' Assembly with trough
13D 1 9951009 Air Foil 7' Assembly with trough
13E 1 9951003 Air Foil 8' Assembly with trough
14 4 1861400 Pulley, Front or Rear, 1-3/16 Dia. (rear of 4', 5', 6' only) – NOT SHOWN
15 2 4949902 Cable, Sash 130" – NOT SHOWN
16 2 9741900 Sheave, (Rear 8')
17 4 9742100 Bronze Bearing, Flanged Rear – NOT SHOWN
18 4 1920100 Clamp, Cable Replacement – NOT SHOWN
19 2 1972100 S-Hook – NOT SHOWN (to attach weight to cable)
20A 1 9946300 Wiring Harness, Main
21 1 9961500, 01, 02, 03, 04 Front Panel, 4', 5', 6', 7', 8'
