Illustration A-1 indicates the location of the following service parts:
Item Quantity Part No. Description
1A 1 9823700 Valve, Labconco (Water) 1/4" Compression Fitting
1B 1 9823701 Valve, Labconco (Water) 3/8" Compression Fitting
1C 1 9817000 Valve, Labconco 1/4" Compression Fitting (AIR, GAS, VAC, NIT, etc.)
1D 1 9817001 Valve, Labconco 3/8" Compression Fitting (AIR, GAS, VAC, NIT, etc.)
1E 1 9823702 Valve, Labconco Deionized 1/4" Compression Fitting
1F 1 9823703 Valve, Labconco Deionized 3/8" Compression Fitting
1G 1 9818000 Nut, Valve Mounting. (Labconco)
2A 1 9826800 WaterSaver Valve/Gooseneck -GRN
2B 1 9826801 WaterSaver Valve/Connector (VAC) – YEL
2C 1 9826802 WaterSaver Valve/Connector (AIR) – ORG
2D 1 9826803 WaterSaver Valve/Connector (GAS) – BLU
2E 1 9826805 WaterSaver Valve/Connector (HOT WATER) – RED
2F 1 9826806 WaterSaver Valve/Connector (CW) – GRN
2G 1 9826807 WaterSaver Valve/Connector (STEAM) – BLK
2H 1 9826808 WaterSaver Valve/Connector (NITROGEN) – BRN
2I 1 9826809 WaterSaver Valve/Connector (OXYGEN) – LIGHT GREEN
2J 1 9826810 Swivel Gooseneck only – GRN
2K 1 9826812 Swivel Gooseneck only – WHITE
3 1 9818700 thru 08 Knobs (GRAY, GRN, BLU, ORG, YEL, RED, WHT, BLK, BRN)
4A 1 9818800 Hose Barb, GRAY – (NEUTRAL OR ARGON) – NOT SHOWN
4B 1 9818801 Hose Barb, GREEN - (COLD WATER) – NOT SHOWN
4C 1 9818802 Hose Barb, BLUE – (GAS) – NOT SHOWN
4D 1 9818803 Hose Barb, ORANGE – (AIR) – NOT SHOWN
4E 1 9818804 Hose Barb, YELLOW – (VACUUM) – NOT SHOWN
4F 1 9818805 Hose Barb, RED – (HOT WATER) – NOT SHOWN
4G 1 9818806 Hose Barb, WHITE – (DEIONIZED WATER) – NOT SHOWN
4H 1 9818807 Hose Barb, BLACK – (NEUTRAL OR STEAM) – NOT SHOWN
4I 1 9818808 Hose Barb, BROWN – (NITROGEN) – NOT SHOWN
4J 1 9819000 Nut, Hose Barb – NOT SHOWN
5 1 9825500 Label, Knob (contains all the labels)
6 1 9818900 Lens, Knob
7A 1 9947100, 01, 02 115V Duplex Receptacle (GRAY) Right, Left 4' - 6', Left 8' w/ wires
7B 1 9818200 Cover Plate 115V Duplex
7C 1 9947103, 04, 05 115V GFCI Duplex Receptacle (GRAY) Right 4' - 6', Left 8' w/ wires
7D 1 9818100 Cover Plate, 115V GFCI
7E 1 9818300 Cover Plate, Blank
Protector XLE Re
p
lacement Parts
