La Crosse Technology, Ltd. Page 1

WT-5220U-IT FAQS

The links below will work in most PDF viewers and link to the topic area by clicking the link. We

recommend Adobe Reader version 10 or greater available at: http://get.adobe.com/reader

CONTENTS

WT-5220U-IT FAQS .................................................................................................................. 1

Batteries ................................................................................................................................ 2

Clock Factory Restart ........................................................................................................ 2

Outdoor Temperature Transmitter ............................................................................... 2

Compatible Outdoor Transmitters .................................................................................... 2

Fahrenheit/Celsius .............................................................................................................. 2

Flashing Outdoor Temperature ......................................................................................... 2

Dashes shown for Outdoor Temperature ........................................................................ 3

Inaccurate Outdoor Temperature Reading ..................................................................... 3

Intermittent Outdoor Temperature .................................................................................. 3

Outdoor Temperature Is Stuck or OFL ............................................................................ 4

Outdoor Transmitter Fell and No Longer Works ............................................................ 4

Outdoor Transmitter Drains Batteries Quickly ............................................................... 4

Mounting/Positioning Outdoor Transmitter .................................................................... 4

Position Clock ...................................................................................................................... 5

Distance/Resistance/Interference .................................................................................... 5

Projection Alarm Clock ..................................................................................................... 6

How tall are the Time Numbers? ...................................................................................... 6

12-Hour or 24-Hour Time Format .................................................................................... 6

Power Requirements .......................................................................................................... 6

Inaccurate Indoor Temperature Reading........................................................................ 6

Set Time Alarm ................................................................................................................... 7

Activate/Deactivate Time Alarm ....................................................................................... 7

Snooze Alarm ...................................................................................................................... 7

Time is off by hours ............................................................................................................ 7

Daylight Saving Time ......................................................................................................... 7

Manually Set Time/Calendar/Alarm: Program Menu ................................................... 8

Display Modes...................................................................................................................... 8

Projection ........................................................................................................................... 9

Change projection orientation .......................................................................................... 9

Project temperature only ................................................................................................... 9

Summary of content (10 pages)

PAGE 1
WT-5220U-I T F AQ S The links below will work in most PDF viewers and link to the topic area by clicking the link. We recommend Adobe Reader version 10 or greater available at: http://get.adobe.com/reader CONTENTS WT-5220U-IT FAQS .................................................................................................................. 1 Batteries ................................................................................................................................
PAGE 2
Projected temperature is dashes ..................................................................................... 9 Projection is dim ................................................................................................................. 9 Projection does not show .................................................................................................. 9 Clock Has Missing Segments ............................................................................................
PAGE 3
 The outdoor Temperature reading will flash when the connection is first lost or intermittent between the clock and the outdoor transmitter.  Distance/Resistance is generally the cause of intermittent connection or loss of connection between the transmitter and the clock.  Check the position of the clock. Turn the clock 90 degrees towards the outdoor transmitter for better reception.  Try the quick connect or factory restart.  Batteries often resolve the connection issue.
PAGE 4
 If the temperature remains on while in the house then it is likely a distance/resistance issue. Move the transmitter to different locations outside to find a location where the temperature reading will hold.  Distance/Resistance can cause loss of transmitter signal.  Check Batteries. Outdoor Temperature Is Stuck or OFL  The last outdoor reading may remain (not change) for several hours when connection is lost.
PAGE 5
 Mount the transmitter on the North side to prevent sun from causing incorrect readings.  Mount at least 6 feet in the air for a strong signal.  Outdoor transmitters are water resistant but not water proof.  Avoid more than one wall between the transmitter and the Clock.  Do not mount near electrical wires, transmitting antennas or other items that will interfere with the signal.  RF (radio frequency) signals do not travel well through moisture or dirt.
PAGE 6
 Consider the distance the clock is located away from other electronic in the home. Resistance:  Obstacles such as walls, windows, stucco, concrete, and large metal objects can reduce the range.  When considering the distance between the transmitter and the clock (330 feet open air) cut that distance in half for each wall, window, tree, bush or other obstruction in the signal path.  Closer is better.  Do not mount the transmitter on a metal fence. This significantly reduces the effective range.
PAGE 7
Set Time Alarm 1. Press and hold the AL/HOUR button for five seconds. The Alarm Time begins to flash. 2. Use the MODE/MIN button to set the Minute and the AL/HOUR button to set the Hour. 3. Press SNOOZE and you are done. Activate/Deactivate Time Alarm  Press, briefly hold, and then release the AL/HOUR button to turn alarm On or Off.  When the alarm is ON, you will see an alarm icon ((●)) next to the word outdoor.  The icon will not show when the alarm is off.
PAGE 8
direction, locate the Clock near an outside wall and point the unit in this general direction. Manually Set Time/Calendar/Alarm: Program Menu TIP: Press only one button at a time while setting the clock. There are five function buttons: AL/HOUR, Sun Icon (sun) Directional Icon (four arrows) MODE/MIN with SNOOZE above the time display. 1. TIME ZONE: Press and hold the MODE/MIN button until the display flashes. The Time Zone will flash, showing a number following by the letter h.
PAGE 9
Projection Change projection orientation  Arrow button: The button has an icon that is a set of four arrows pointing up, down, left, and right.  Each press of this button will change the direction of the numbers projecting onto the ceiling by a quarter turn. Project temperature only  This clock is designed to continually alternate between time and outdoor temperature. This cannot be adjusted.
PAGE 10
 This is generally a power related issue. Check that the AC cord is plugged in correctly.  Batteries may be overpowered or underpowered. Remove batteries and AC cord from clock.  Press any button 20 times. Leave the clock unpowered for 1-2 hours.  Install AC cord and/or fresh alkaline batteries with correct polarity. Clock Has Distorted Display  On a brand new clock check for thin plastic films of printed scratch guard that may be on the upper and lower screen of the clock.
