4.3.1. Display the Cu rrent Transmit Configuration
When “1” is entered in the “System Configuration Menu,” the “Current Configuration
Information” screen appears with a summary of the AIS AtoN’s existing setup, as
show in Figure 4--4. Press any key to return to the main “System Configuration
Menu.” Table 4--2 describes the parameters in this screen, which are some of the
basic features in the AIS AtoN.
Figure 4--4. View the Current Configuration Information Screen
Tab le 4--2. Current Config u ration Field Descriptions
Field Description
Software Displays the revision of the software currently running
on the AtoN
AtoN Configuration Describes the type of AIS AtoN unit
Serial Number Displays the serial number of the AIS AtoN unit
MMSI Shows the MMSI of the AIS AtoN, which is set at “0” as
a factory default
AtoN Name Displays the name of the AIS AtoN I.D. string
Configured Lat/Lon Indicates the charted location (latitude and longitude)
of the AtoN, as it is shown on international charts
