RESERVED
PIN
1
2
3
SIGNAL NAME
UTILITY #1(ARM)---TXD
4
5
6
7
RESERVED
GROUND
8
9
UTILITY #1(ARM)---RXD
RESERVED
RESERVED
RESERVED
RESERVED
Figure 2--6. Utility #1 Connector Pinout
RESERVED
PIN
1
2
3
SIGNAL NAME
UTILITY #2(DSP)---TXD
4
5
6
7
RESERVED
GROUND
8
9
UTILITY #2(DSP)---RXD
RESERVED
RESERVED
RESERVED
RESERVED
Figure 2--7. Utility #2 Connector Pinout
