Manual

15
PARTS LIST
WIRE SSELECTION TTABLE
DESCRIPTION COLOR LENGTH PART NNO.
Wire, High Limit to
Air Proving Switch Black 60 in. 20425
Wire, Gas Control
to High Limit Black 41 in. 21592
Wire, Gas Control
to Thermostat White 28 in. 21593
Wire, Air Proving Switch
to Thermostat Black 55 in. 21591
Wire, Motor Black 52 in. 21589
Wire, Motor White 52 in. 21590
FASTENER SSELECTION TTABLE
DESCRIPTION APPLICATION PART NNO.
Screw, #8 x 3/8 Case 07288
Item Description Part NNumber
1 Regulator, Single Stage (Propane Gas) 09914
Regulator, Second Stage (Propane Gas) 06665
2 Hose, 1/2 in. x 10 ft. 20504
3 Adapter, 1/2 NPT x 1/2 NPS 02894
4 Bracket, Gas Control Valve 23975
4a Cover 23972
5 Screw 09425
6 Valve, Gas Control (Propane Gas) 21615
Valve, Gas Control (Natural Gas) 21616
7 Manifold 07826
8 Orifice, Burner (Propane Gas) 21573
Orifice, Burner (Natural Gas) 21574
9 Thermocouple, 18 in. 03555
10 Tube, Pilot 22204
11 Cord, Power, 5 ft. 01220
12 Orifice, Pilot (Propane Gas) 02689
Orifice, Pilot (Natural Gas) 02740
13 Screw, Pilot 03070
14 Stud 07827
15 Pilot Assembly with Orifice (Propane Gas) 02729
Pilot Assembly with Orifice (Natural Gas) 02741
16 Gasket 06974
17 Shield, Pilot 20264
18 Screw, Burner Mounting 02688
19 Spacer 02687
20 Burner 03453
21 Bracket, Thermostat 05493
22 Thermostat, with Bracket 05568
23 Cover, Junction Box 03231
24 Junction Box 03230
25 Switch, High Limit 05566
26 Chamber, Heat 21602
27 Case Assembly (1) 02673
28 Panel, Motor End 07332
29 Panel, Burner End (1) 07333
30 Motor 20554
31 Mount, Motor 03764
32 Switch, Air Proving 02680
33 Wheel, Fan 02684
34 Flapper, Sail 02441
35 Housing, with Air Proving Switch and Flapper 05570
36 Base 21586
37 Bolt 07908
38 Washer 01589
39 Spacer 07905
(1) Specify model number for dataplate when ordering.
