located at a position on the screen that indicates the
relative bearing and range of the intruder aircraft.
In general, the
SKY899 issues a TA when it detects an
intruder aircraft within
30 seconds of a possible collision,
or within a
0.55 nmi horizontal radius and a ±800 ft
relative altitude range of your aircraft. (See chapter
4 for
details.)
Vertical Trend Arrow A vertical trend arrow
indicates that the intruder aircraft is ascending (up
arrow) or descending (down arrow) faster than
500 fpm.
No arrow is shown for intruder aircraft in level flight, or
for those moving vertically slower than
500 fpm, or for
non-altitude-reporting intruder aircraft.
Operating Mode Button Pressing this button
when it’s labeled
>
STB switches the SKY899 out of
normal operating mode and into standby. Pressing the
button when it’s labeled
>
OPR switches the SKY899
out of standby and into normal operating mode.
Label for Operating Mode Button This
on-screen label identifies the function of the
adjacent button. The
>
STB label appears on the
traffic screen and means go to standby. The
>
OPR label appears on the standby screen and
means go to normal operating mode. If your
aircraft has a squat switch, the
>
STB label only
appears when your aircraft is on the ground.
Display Range Button Pressing this button when
the
SKY899 is in standby has no effect. Pressing the
button when the
SKY899 is in operating mode toggles
the
SKY899 display range between 15, 6, and 2 nmi as
reflected in the on-screen display range indicator.
Display Range Indicator The unhighlighted
version of the indicator (present only on the
Standby
screen) simply reminds you that the adjacent button
can be used to select the display range once you
switch into operating mode. The highlighted version
of the indicator (present only in operating mode)
identifies the currently selected display range (
15, 6, or
2 nmi).
