FXAlg #715: Dual MovDelay ¥ FXAlg #716: Quad MovDelay
Algorithm Reference-89
Ln Mix, Rn Mix Adjusts the mix levels for each moving delay circuit. The resulting sum makes up the
wet signal. Negative values polarity-invert the signal.
L Pan, R Pan, Ln Pan, Rn Pan The output panning position of each moving delay circuit. 0% is center; Negative
values pan left, while positive values pan right.
L Dry Pan, R Dry Pan Adjusts the output pan position of the input dry signals. The dry level is controlled with
Wet/Dry. 0% pans to center; Negative values pan left while positive values pan right.
L1/Dry->L2, R1/Dry->R2 Adjusts the input mix into the second pair of moving delay circuits in Quad
MovDelay. The value represents a ratio of the output of the Þrst moving delay circuit
and the input dry signal. A value of 0% allows only the input dry signal to be fed into
the second delay, while a value of 100% only allows the Þrst delay to be fed into the
second.
L Delay, R Delay, Ln Delay, Rn Delay Adjusts the delay time for each moving delay circuit, which is the center of
LFO excursion.
L LFO Mode, R LFO Mode, Ln LFO Mode, Rn LFO Mode Adjusts the LFO excursion type. In Flange mode, the
LFO is optimized for ßange effects and LFO Dpth adjusts the excursion amount. In
ChorTri and ChorTrap modes, the LFO is optimized for triangle and trapzoidal pitch
envelopes respectively, and LFO Dpth adjusts the amount of chorus detuning. In Delay
mode, the LFO is turned off leaving a basic delay. LFO Rate and LFO Dpth in Delay
mode are disabled.
L LFO Rate, R LFO Rate, Ln LFO Rate, Rn LFO Rate Adjusts the LFO speed for each moving delay circuit.
L LFO Dpth, R LFO Dpth, Ln LFO Dpth, Rn LFO Dpth In Flange LFO mode, this adjusts an arbitrary LFO
excursion amount. In ChorTri and ChorTrap modes, this controls the chorus detune
amount. In delay mode, this is disabled.
L Feedback, R Feedback, Ln Fdbk, Rn Fdbk Adjusts the level of each moving delay circuits output signal fed
back into their own inputs. Negative values polarity-invert the feedback signal.
L HF Damp, R HF Damp, Ln HF Damp, Rn HF Damp Adjusts the cutoff frequency of a 1-pole (6dB/oct)
lowpass Þlter in each moving delay circuit.
