User Guide

Combination Algorithms [Ò+Ó]
Algorithm Reference-72
Dly Time L, Dly Time R The delay lengths of each channel in beats. The duration of a beat is speciÞed with the
Tempo parameter. The delay length in seconds is calculated as beats/tempo * 60
(sec/min).
Dly Fdbk L, Dly Fdbk R The amount of the output of the effect that is fed back to the input.
Dly HFDamp Controls the cutoff frequency of a 1 pole (6dB/oct slope) lowpass Þlter in the feedback
path. The Þlter is heard when either Dly Fdbk or LsrCntour is used.
Dly Image This parameter controls the amount of image shifting during each feedback
regeneration, and is heard only when Dly Fdbk is used. Small positive values shift the
image to the right, while small negative values shift to the left. Larger values tend to
shift the image so far that the image gets scrambled, and in some cases create ambience.
Combination 4-Tap:
Combination 4-Tap is a tempo based 4 tap delay with feedback used in combination algorithms. Parameters
associated with the 4 tap effect start with Ò4TÓ. The control over the feedback tap and individual output taps is
essentially the same as the 4-Tap Delay BPM algorithm, with the exception that the delay times will pin at the
maximum delay time instead of automatically cutting their times in half. For more information, see the section on
4-Tap Delay BPM of this book, FXAlg #132.
PAGE 1
PAGE 2:
Dly Time L 0 to 32 bts Dly Time R 0 to 32 bts
Dly Fdbk L -100 to 100% Dly Fdbk R -100 to 100%
Dly HFDamp 0 to 32 bts Dly Image -100 to 100%
4T Tempo System; 1 to 255 BPM
4T LoopLen 0 to 8 bts
4T FB Lvl -100 to 100%
Tap1 Delay 0 to 8 bts Tap3 Delay 0 to 8 bts
Tap1 Level -100 to 100% Tap3 Level -100 to 100%
Tap1 Bal -100 to 100% Tap3 Bal -100 to 100%
Tap2 Delay 0 to 8 bts Tap4 Delay 0 to 8 bts
Tap2 Level -100 to 100% Tap4 Level -100 to 100%
Tap2 Bal -100 to 100% Tap4 Bal -100 to 100%
