User Guide

FXAlg #3: Gated MiniVerb
Algorithm Reference-7
Parameters:
PAGE 1
PAGE 2
PAGE 3
Wet/Dry A simple mix of the reverb sound with the dry sound. When set fully dry (0%), the gate
is still active.
Out Gain An overall level control of the effectÕs output (applied after the gate).
Gate Thres The input signal level in dB required to open the gate (or close the gate if Gate Duck is
on).
Gate Duck When set to ÒOffÓ, the gate opens when the signal rises above threshold and closes when
the gate time expires. When set to ÒOnÓ, the gate closes when the signal rises above
threshold and opens when the gate time expires.
Gate Time The time in seconds that the gate will stay fully on after the signal envelope rises above
threshold. The gate timer is started or restarted whenever the signal envelope rises
above threshold.
Gate Atk The attack time for the gate to ramp from closed to open (reverse if Gate Duck is on)
after the signal rises above threshold.
Gate Rel The release time for the gate to ramp from open to closed (reverse if Gate Duck is on)
after the gate timer has elapsed.
Signal Dly The delay in milliseconds (ms) of the reverb input signal relative to the side chain signal.
By delaying the reverb signal, the gate can be opened before the reverb signal rises
above the gating threshold.
For descriptions of the other parameters, see the previous section, FXAlgs #1-2.
Wet/Dry 0 to 100%wet Out Gain Off, -79.0 to 24.0 dB
Rvrb Time 0.5 to 30.0s, Inf HF Damping 16 to 25088 Hz
L Pre Dly 0 to 620ms R Pre Dly 0 to 620 ms
Room Type Hall1 Diff Scale 0.00 to 2.00x
Size Scale 0.00 to 4.00x
Density 0.00 to 4.00x
Gate Thres -79.0 to 0.0 dB Gate Time 0 to 3000 ms
Gate Duck In or Out Gate Atk 0.0 to 228.0 ms
Gate Rel 0 to 3000 ms
GateSigDly 0.0 to 25.0 ms
Reduction
-dB 60 40 * 16 * 8 4 0
