User Guide

FXAlgs #150Ð153: Choruses
Algorithm Reference-54
Parameters (Dual Chorus 2):
PAGE 1
PAGE 2
PAGE 3
PAGE 4
W
et/Dry The relative amount of input (dry) signal and chorus (wet) signal that appears in the
Þnal effect output mix. When set to 0%, the output is taken only from the input. When
set to 100%, the output is all wet. Negative values polarity-invert the wet signal.
Out Gain The overall gain or amplitude at the output of the effect.
Fdbk Level The level of the feedback signal into the delay line. The feedback signal is taken from the
LFO1 delay tap. Negative values polarity-invert the feedback signal.
Xcouple Controls how much of the left channel input and feedback signals are sent to the right
channel delay line and vice versa. At 50%, equal amounts from both channels are sent to
both delay lines. At 100%, the left feeds the right delay and vice versa.
HF Damping The amount of high-frequency content of the signal that is sent into the delay lines. This
control determines the cutoff frequency of the one-pole (-6dB/octave) lowpass Þlter.
Pitch Env The pitch of the chorus modulation can be made to follow a triangular ÒTriangleÓ
envelope (rise-fall-rise-fall) or a trapzoidal ÒtrapzoidÓ envelope (rise-hold-fall-hold).
L Wet/Dry -100 to 100%wet R Wet/Dry -100 to 100%wet
L Out Gain Off, -79.0 to 24.0 dB R Out Gain Off, -79.0 to 24.0 dB
L Fdbk Lvl -100 to 100% R Fdbk Lvl -100 to 100%
Xcouple 0 to 100%
L Tap1 Lvl -100 to 100% R Tap1 Lvl -100 to 100%
L Tap2 Lvl -100 to 100% R Tap2 Lvl -100 to 100%
L Tap3 Lvl -100 to 100% R Tap3 Lvl -100 to 100%
L Tap1 Pan -100 to 100% R Tap1 Pan -100 to 100%
L Tap2 Pan -100 to 100% R Tap2 Pan -100 to 100%
L Tap3 Pan -100 to 100% R Tap3 Pan -100 to 100%
L LFO1Rate 0.01 to 10.00 Hz R LFO1Rate 0.01 to 10.00 Hz
L LFO2Rate 0.01 to 10.00 Hz R LFO2Rate 0.01 to 10.00 Hz
L LFO3Rate 0.01 to 10.00 Hz R LFO3Rate 0.01 to 10.00 Hz
L LFO1Dpth 0.0 to 50.0 ct R LFO1Dpth 0.0 to 50.0 ct
L LFO2Dpth 0.0 to 50.0 ct R LFO2Dpth 0.0 to 50.0 ct
L LFO3Dpth 0.0 to 50.0 ct R LFO3Dpth 0.0 to 50.0 ct
L Tap1 Dly 0.0 to 1000.0 ms R Tap1 Dly 0.0 to 1000.0 ms
L Tap2 Dly 0.0 to 1000.0 ms R Tap2 Dly 0.0 to 1000.0 ms
L Tap3 Dly 0.0 to 1000.0 ms R Tap3 Dly 0.0 to 1000.0 ms
L HF Damp 16 Hz to 25088 Hz R HF Damp 16 Hz to 25088 Hz
L PitchEnv Triangle or trapzoid R PitchEnv Triangle or trapzoid
