FXAlg #135: Spectral 4-Tap ¥ FXAlg #136: Spectral 6-Tap
Algorithm Reference-44
FXAlg #135: Spectral 4-Tap ¥
FXAlg #136: Spectral 6-Tap
Tempo based 4- and 6-tap delays with
added shapers and resonant comb filters on each tap
Allocation Units: 2 for Spectral 4-Tap; 3 for Spectral 6-Tap
Spectral 4 Tap and Spectral 6 Tap are respectively 2- and 3-PAU tempo-based multi-tap delay effects. They are
similar to simple 4- and 6-tap delays with feedback, but have their feedback and output taps modified with shapers
and filters. In the feedback path of each channel are a diffuser, hipass filter, lowpass filter, and imager. Each delay
tap has a shaper, comb filter, balance and level controls with the exception of Tap 1, which does not have a comb
filter.
Spectral 6-Tap
R Input
R Output
R Dry
Delay
Imaging
(Individual Shaper, Comb
and Gain for Taps 2-6)
Shaper
Comb
Shaper
Delay
Shaper
Comb
Shaper
L Dry
L Input
L Output
Feedback
Tap 1
Tap 1
(Individual Shaper, Comb
and Gain for Taps 2-6)
Diffuser
Diffuser
