User Guide

FXAlg #131: 4-Tap Delay ¥ FXAlg #132: 4-Tap Delay BPM
Algorithm Reference-39
Parameters:
PAGE 1
PAGE 2
PAGE 3
Tempo Basis for the delay lengths, as referenced to a musical tempo in bpm (beats per minute).
When this parameter is set to ÒSystemÓ, the tempo is locked to the internal sequencer
tempo or to incoming MIDI clocks. When it is set to ÒSystemÓ, sources (FUNs, LFOs,
ASRs etc.) will have no effect on the Tempo parameter.
LoopLength The delay length of the Loop tap. If the feedback is turned up, this parameter sets the
repeating delay loop length. The loop length is speciÞed as a fraction or multiple of the
tempo, in ÒbeatsÓ. The length of a delay loop in seconds can be calculated as T =
(beats/tempo) * 60.
Tapn Delay The delay lengths of the taps (n = 1...4). as tempo beat durations. The delay length is
speciÞed as a fraction or multiple of the tempo, in ÒbeatsÓ. The length of a delay in
seconds can be calculated as T = (beats/tempo) * 60. Use the output taps to create
interesting rhythmic patterns within the repeating loop.
Wet/Dry 0 to 100%wet Out Gain Off, -79.0 to 24.0 dB
Fdbk Level 0 to 100% Tempo System, 1 to 255 BPM
Dry Bal -100 to 100%
HF Damping 16 Hz to 25088 Hz Hold On or Off
LoopLength 0 to 32 bts
Tap1 Delay 0 to 32 bts
Tap2 Delay 0 to 32 bts
Tap3 Delay 0 to 32 bts
Tap4 Delay 0 to 32 bts
Tap1 Level 0 to 100% Tap1 Bal -100 to 100%
Tap2 Level 0 to 100% Tap2 Bal -100 to 100%
Tap3 Level 0 to 100% Tap3 Bal -100 to 100%
Tap4 Level 0 to 100% Tap4 Bal -100 to 100%
