FXAlg #1: MiniVerb ¥ FXAlg #2: Dual MiniVerb

Algorithm Reference-3

Simplified block diagram of Dual MiniVerb

Dual MiniVerb has a full MiniVerb, including Wet/Dry, Pre Delay and Out Gain controls, dedicated to each of the

left and right channels. The two blocks in the diagram above labeled ÒMiniVerbÓ contain a complete copy of the

MiniVerb on the previous page. Dual MiniVerb gives you independent reverbs on both channels which has obvious

benefits for mono material. With stereo material, any panning or image placement can be maintained, even in the

reverb tails. This is pretty unusual behavior for a reverb, since even real halls will rapidly delocalize acoustic images

in the reverberance. Since maintaining image placement in the reverberation is so unusual, you will have to

carefully consider whether it is appropriate for your particular situation. To use Dual MiniVerb to maintain stereo

signals in this manner, set the reverb parameters for both channels to the same values. The Dry Pan and Wet Bal

parameters should be fully left (-100%) for the left MiniVerb and fully right (100%) for the right MiniVerb.

Parameters (MiniVerb):

PAGE 1

PAGE 2

Wet/Dry 0 to 100%wet Out Gain Off, -79.0 to 24.0 dB

Rvrb Time 0.5 to 30.0 s, Inf HF Damping 16 to 25088 Hz

L Pre Dly 0 to 620 ms R Pre Dly 0 to 620 ms

Room Type Hall1 Diff Scale 0.00 to 2.00x

Size Scale 0.00 to 4.00x

Density 0.00 to 4.00x

Pan

MiniVerb Balance

Balance

L Input

R Input

L Output

R Output

MiniVerb

Dry

Wet
