DO0262R00-MGW-UM-DMX-EN
6 / 25
3
Overview
3.1
Functionality
The KUNBUS Gateway is a protocol converter. It allows
communication between networks with different protocols.
Illustration1:
Functionality as a slave
Overview
1
...
...
4
5
6
7
8
...
...
25
