6 Technical Data
6.1 Technical Data
Dimensions
Width 22.5 mm
Height 96 mm
Depth 110.4 mm
Weight 90 g
Electrical data
Power supply 24 V DC
Power consumption during operation
(cyclical data exchange)
100mA
Status display LED
Environmental conditions
Ambient temperature 0 – 60 °C
Storage temperature - 25 – 60 °C
Humidity 93% (at 40 °C)
Condensing Not allowed
Protection class
Control cabinet
Housing
Terminal area
IP54
IP20
IP20
Assembly data
DIN rail 35 x 7.5 mm
Height 96 mm
Depth 110.4 mm
DMX protocol
Protocol DMX 512
Communication type Unidirectional
A sender sends the data without re-
ceiving feedback. A receiver accepts
the data on the bus without feed-
back.
Baudrate 250 kBaud
Transmission RS 485
Byte transmission 8N2 (8 data bits, no parity, 2 stop
bits)
Special feature A DMX package starts with 88 us (22
bit lengths) low level (logical 0). This
section is called "break".
